Fuel tank semi trailer price is designed and manufactured in accordance with the relevant national regulations and standards, and the automatic longitudinal circular seam flaw detection and welding, the process is beautiful and reliable, and the one-time molding does not leak.
All accessories are movable installation structure, which is convenient for maintenance and disassembly. The functional parts of fuel tank semi trailer price are designed according to the announcement position and application needs, and the reasonable pipeline direction and operation method are designed, and the humanized design is clear at a glance.
Fuel Tank Semi Trailer Price | Fuel Tanker 35,000 Litres - 45,000 Litres
Fuel Tank Semi Trailer Price | Fuel Tanker 35,000 Litres - 45,000 Litres
Fuel Tank Semi Trailer Price | Fuel Tanker 35,000 Litres - 45,000 Litres
Tare Weight (semi trailer): About 8000-12800kg
Total volume: 35,000-45,000 liters
Tank Body Material: 5mm or 6mm/Q235 carbon steel
End plate: 5mm or 6mm/Q235 carbon steel
Manhole Cover: Carton steel
Discharging Valve: Diameter is 3 or 4 inch
Compartments: 4 Compartments
Discharging Pipe: 4 inch rubber hose,2pcs,6m/each
Cat Walk: With (common model or special design)
Main beams: Welded design or special design I beam, connected by bolts and nuts Q345 carbon steel material
Axle: 3 axles,12T/13T/16T,BPW/ FUWA/ TITAN brand
Landing Gear: JOST(D200T) or China brand 28T
Kingpin: JOST 2.0 or 3.5 inch bolt-in king pin
Suspension: Mechanical suspension /Germany or America type /Air Suspension
Leaf Spring: 90(w)mmx13(thickness)x10layers or 10mm x12mmx12 layers
Pneumatic Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tank
Rim: 9.00-22.5/8.00-20/8.5-20 Chinese brand
Tire: 12.00R22.5/315.80R22.5/11.00R20/12.00R20 brand can be optional
ABS: Optional
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layer of top coats.
Accessories: One standard tool box
Shipping Terms: By bulk cargo, RORO or 40HQ containers
Fuel Tank Semi Trailer Price | Fuel Tanker 35,000 Litres - 45,000 Litres
Through this video, you can learn about different types of fuel tanker trailers, as well as the process, testing, packaging and customer feedback, etc.
